Technical details

• Height and width can be individually adjusted, modules are laid across the top.
• The assembly table has an incline of 10° (- 1.5°).
• There is a main pipe in each row of plants, over which a row of modules sits.
• Only two rows are connected to each other via inclined pipes.
• Pipe components made of steel cut / stamped or galvanized according to DIN EN 1461.
• Distance from lower edge of module to floor approx. 3.50 (± 0.1 m) according to statics according to EOROCODE.
• Semi-transparent modules, fastened with module clamps ; Module spacing 10 mm, without sealing profile.
• Lateral cantilever overhang approx. 1.25 - 1.50 m (outside module edge) Ramming depths between 1.50 m and 3.00 m meters according to the specification of the soil report is necessary for the ramming depth and the distances must be measured.
• Flexibility in terms of wingspan and maximum harvesting height

power connection

Photovoltaic self-consumption is worthwhile if the electricity costs saved are greater than the feed-in tariff. (EEG 2023)

The excess electricity is ideally fed into the grid via the local energy supplier.

As a rule, the customer takes care of the grid connection himself in cooperation with the local grid operator.

But direct marketing can also be worthwhile in view of the rapid increase in electricity prices on the exchange. (as of April 2022)
